MWA

Waste Adaptor

Internal Pipe connection
Push in pipes between 32 - 50mm
EPDM Rubber
Easy cut out ridges

The Mission Rubber Waste Adaptor will allow waste water pipesThe Mission Rubber Waste Adaptor will allow waste water pipesof 32mm, 40mm and 50mm to be connected directly into 110mm underground drainage pipe. Cut to the correct size and push in.

PHONE Sales & Technical-Team
+44 114 257 0040

Technical Specification

Manufacturer:

MISSION RUBBER (UK) Ltd., Sheffield, S35 9TG, T +44 (0) 114 257 - 0040

Pressure Tightness:

0.5 bar water / -0.3 bar vacuum

Sealing Material:

EPDM rubber according to BS EN 681-1

Temperature Resistance:

-40°C to +120°C, temporary max. temperature +160°C

Standard/Approval:

BS EN 681-1

WASTE ADAPTOR

Reference	Size A (mm)	Size B (mm)	resistant to (bar)
MWA 095	100	32-40-50	0.5

DIN EN 681-1
DIN EN 295-4
